SB AWE32 Developer's Information Pack PART IV MIDI NRPN Implementation •• 91

NRPN LSB 16 (Initial Pitch)

Realtime : Yes

Range : [-8192, 8191]

Unit : cents

Pitch tuning between -8192 and 8191 cents.

NRPN LSB 17 (LFO1 to Pitch)

Realtime : Yes

Range : [-127, 127]

Unit : 9.375 cents

If data value is greater than 0, this will cause a positive (from 0 to maximum) of 1 octave shift at LFO

peak. On the other hand, if data value is smaller than 0, this will cause a negative (from o to minimum) of

1 octave shift at LFO peak.

NRPN LSB 18 (LFO2 to Pitch)

Realtime : Yes

Range : [-127, 127]

Unit : 9.375 cents

If data value is greater than 0, this will cause a positive (from 0 to maximum) of 1 octave shift at LFO

peak. On the other hand, if data value is smaller than 0, this will cause a negative (from o to minimum) of

1 octave shift at LFO peak.

NRPN LSB 19 (Envelope 1 to Pitch)

Realtime : No

Range : [-127, 127]

Unit : 9.375 cents

If data value is greater than 0, this will cause a positive (from 0 to maximum) of 1 octave shift at

envelope peak. On the other hand, if data value is smaller than 0, this will cause a negative (from 0 to

minimum) of 1 octave shift at envelope peak.

NRPN LSB 20 (LFO1 to Volume)

Realtime : Yes

Range : [0, 127]

Unit : 0.1875 dB

Data value smaller than 64 causes a positive phase (from 0 to maximum) volume modulation via LFO1

with magnitude of 12 dB at LFO peak. On the other hand, data value greater than or equals to 64 causes a

negative phase (from 0 to minimum) volume modulation via LFO1 with magnitude of 12 dB at LFO peak.
