35
577mm
exc. handle
knobs
887mm
597mm
560mm
560-574mm
875mm
887mm
878mm if
cooker
trim
is to
overlap
top edge
of shelf
* excluding pipe work
and other projections
4mm
2
Cable
to Hob if
fitted
4mm
2
Cable
To Oven
6mm
2
Cable
if hob fitted
Connector
Box
Oven Door
Fig. 4
Fig. 2
550mm
550mm
min *
Fig. 3
Cabinet
No. 6 x 15mm screw
(4 supplied)
Viewed down through
cabinet
560mm
