Creda Single Oven - Page 28

28
Ventilation Slot 150 cm
2
if cabinet doesn't fit to ceiling
Ventilation Slot
150 cm
2
if cabinet fits
to ceiling
30mm
air
gap
30mm
air
gap
Tall Cabinet
Ventilation Slot
150 cm
2
Cabinet
Side
Trim
Built
Under
560mm min
574mm max
565mm min
excluding pipes
and other projections
575mm min
580mm max
When fitting a hob above an oven always
use these installation instructions
in conjunction with the hob instructions.
Oven Door
Viewed down through
cabinet
560mm
Oven
Fig. 1
Fig. 3
Fig. 2
No. 6 x 15mm
(4 Supplied)
1.5mm
INSTALLATION INSTRUCTIONS
Ventilation Slot
150 cm
2
550mm min
565mm min
560mm
