January
January
2008
2008
Rev. MC5 / 1
Rev. MC5 / 1
Ed. A / 08
Ed. A / 08
27
27
Regulators repair and maintenance
Regulators repair and maintenance
1
1
st
st
stage MC5:
stage MC5:
assembling phases INT
assembling phases INT
• After replacing the OR of the bracket blocking nut, place the INT
bracket between the nut and the 1st stage body. Overcoming the
spring resistance, push the bracket blocking nut on the filter, down
to the threading inside the 1
st
stage body. Screw down the nut
completely, keeping the 1
st
stage against the work-table, in order
to be sure the OR is correctly placed in its own seat.
