1 Service (continued)
Service Manual
15
Parameter table
Table 1B (continued from previous page) This table lists SMART TOUCH control module parameters and where to
access them
Menu
Sub
Item
Parameter Name
(as shown on the LCD screen)
See
Page
Min
Max
Default
User Installer
Value Value Value Access Access
F
1 Temperature Units 21 °F °C °F Yes Yes
2 LCD Backlight Time 21 0 255 240 Yes Yes
3 Freeze Protection; Pump On 21 -22 45 44.6 No Yes
4 Freeze Protection; Burner On 22 -22 45 37.4 No Yes
5 Freeze Protection; Burner Diff 22 0 20 5 No Yes
6 HWG to SH Switching Time 22 0 240 30 No Yes
7 SH to HWG Switching Time 22 0 240 30 No Yes
8 Anti-Cycling Time 22 0 40 10 No Yes
9 Anti-Cycling Differential 22 0 40 1 No Yes
10 HWG Rate Limiting 22 10 100 100 No Yes
11 HWG Type 22 NORMAL ZONE NORMAL No Yes
12 HWG System Pump Mode 22 NORMAL
ALWAYS
ON
ALWAYS
OFF
No Yes
13 Service Mode Timeout 22 0 40 40 No Yes
14 Controlling Sensor 22 0 4 2 No Yes
15 Inlet Control Time Delay 22 0 40 3 No Yes
16 Modulation Factor 23 40 100 100 No Yes
17 Min Boiler Rate 23 4% 100% 100% No Yes
18 Freeze Protection; Pump Diff(°F)* 23 0 9 5.4 No Yes
G
1 SH Night Setback Offset Temp 23 0 90 0 No Yes
2 SH Night Setback Mon End 23 N/A N/A N/A No Yes
3 SH Night Setback Mon Begin 23 N/A N/A N/A No Yes
4 SH Night Setback Tue End 23 N/A N/A N/A No Yes
5 SH Night Setback Tue Begin 23 N/A N/A N/A No Yes
6 SH Night Setback Wed End 23 N/A N/A N/A No Yes
7 SH Night Setback Wed Begin 23 N/A N/A N/A No Yes
8 SH Night Setback Thur End 23 N/A N/A N/A No Yes
9 SH Night Setback Thur Begin 23 N/A N/A N/A No Yes
10 SH Night Setback Fri End 23 N/A N/A N/A No Yes
11 SH Night Setback Fri Begin 23 N/A N/A N/A No Yes
12 SH Night Setback Sat End 23 N/A N/A N/A No Yes
13 SH Night Setback Sat Begin 23 N/A N/A N/A No Yes
14 SH Night Setback Sun End 23 N/A N/A N/A No Yes
15 SH Night Setback Sun Begin 23 N/A N/A N/A No Yes
ADVANCED SETUPSH NIGHT SETBACK
*This parameter is only available through the PC program.
