Crestron CNX-PAD8A Professional Audio Distribution Processor
Professional Audio Distribution
Processor: CNX-PAD8A
Description
Functional Description
The Crestron Professional Audio Distribution Processor, CNX-PAD8A is an
enhanced version of Crestron's professional high-end audio distribution system. It
delivers audio from up to eight sources into as many as eight separate rooms and can
be expanded with additional CNX-PAD8A chassis to 32 rooms (using the optional
Audio Switcher Bussing Kit). Powered by a Crestron control system, the
CNX-PAD8A can be programmed to select any available audio source, choose a
room destination, and distribute a pre-amplified signal to as many as eight room
amplifiers, each of which can be chosen according to its application. A general
application of the CNX-PAD8A is shown on the next page. In addition, the
CNX-PAD8A provides the mixing of stereo sources to mono. Any Crestron user
interface – from keypad to touchpanel – provides access and control to the
CNX-PAD8A's functions. The CNX-PAD8A should typically be installed with the
Crestron amplifier (i.e., CNAMPX-16x60). The table after this paragraph provides a
summary of the enhancements associated with the CNX-PAD8A.
CNX-PAD8A Functional Summary
CNX-PAD8A
Professional Audio Distribution Processor
* Electronic mute increased to >-92 dB
* Signal to noise ratio improved to >-100 db at room outputs
* Crosstalk between channels has been reduced to >-92 dB
* Built in mono capability
* Improved dynamic range
* Increased gain range
Operations Guide – DOC. 8174 Professional Audio Distribution Processor: CNX-PAD8A • 1
