Crestron TSW-70 Series Getting Started

Crestron Electronics, Inc.
15 Volvo Drive, Rockleigh, NJ 07647
Tel: 888.CRESTRON
Fax: 201.767.7656
www.crestron.com
Product Information - Doc. 8557CO
(2054677)
03/11/20
The device may contain radios capable of transmitting in the
5150–5350 MHz frequency range (such as 5GWi-Fi® networks).This
frequency is restricted to indoor use only.
The Waste Electrical & Electronic Equipment (WEEE) directive
marking on a product indicates that it should not be disposed of with
general waste. Instead, you are encouraged to reuse or recycle the
product in accordance with Directive 2012/19/EU of the European
Union. Proper disposal of this product will help prevent potential
negative effects on the environment and human health, which could
otherwise be caused by inappropriate waste handling. Penalties may
be applicable for incorrect disposal of this waste, in accordance with
your national legislation. For information about recycling this
product, please contact your household waste disposal service, your
original distributor, or Crestron.
Power Rating: Input 48 VDC350 mA(802.3at Type 1), Input 48
VDC600 mA(802.3at Type 2)
USBCurrent:Total 1 A supported
Product Specifications
M201923001 M201923002 M201923003
Size 5 in. 7 in. 10.1 in.
Panel
Resolution
1280 x 720 1280 x 800 1290 x 1200
Power
Rating
Input 48
VDC350 mA
(802.3at
Type1);
Input 48 VDC
600mA
(802.3at
Type2)
Input 48
VDC350 mA
(802.3at
Type1);
Input 48 VDC
600mA
(802.3at
Type2)
Input 48
VDC350 mA
(802.3at
Type1);
Input 48 VDC
600mA
(802.3at
Type2)
Inputs/
Outputs
1 RJ-45
Ethernet port;
2 USB 2.0
ports
1 RJ-45
Ethernet port;
2 USB 2.0
ports
1 RJ-45
Ethernet port;
2 USB 2.0
ports
RFTechnical Specification
Operating
Frequency
Bluetooth® 4.1:2.402-2.480 GHz;
802.11 b/g/n: 2.412-2.484 GHz;
802.11 a/n/ac: 5.15-5.25 GHz; 5.725-5.825
GHz
Number of
Channels
Bluetooth 4.1:1–79 channels;
802.11 b/g/n: 1–11 CH (US, Canada), 1–13 CH
(ETSI, AS, NZS, Korea, China), 1–14 CH
(Japan);
802.11 a/n/ac: CH 36, CH 38, CH 40, CH 42,
CH44, CH46, CH 48 (US, Canada, ETSI, AS,
NZS, Korea, China, Japan)
Channel
Spacing
Bluetooth BR/EDR = 1 MHz, LE=2 MHz;
802.11 b/g/n: 5 MHz;
802.11 a/n/ac: 5 MH
RFOutput
Power -
Maximum
802.11 b (2.4 GHz): 16 dBm (USA, Canada),
19.02 dBm (ETSI, AS, NZS, Korea, China,
Japan), 15.99 dBm (CH 14);
802.11 g (2.4 GHz): 13 dBm (USA, Canada);,
14.32 dBm (ETSI, AS, NZS, Korea, China,
Japan);
802.11 n HT20 (2.4 GHz): 13 dBm (USA,
Canada), 14.49 dBm (ETSI, AS, NZS, Korea,
China, Japan);
802.11 n HT40 (2.4 GHz): 12 dBm (USA,
Canada); 15.89 dBm (ETSI, AS, NZS, Korea,
China, Japan);
802.11 a (5GHz): 14 dBm (USA, Canada),
13.94 dBm (ETSI, AS, NZS, Korea, China,
Japan);
802.11 n HT20 (5GHz): 14 dBm (USA,
Canada), 13.86 dBm (ETSI, AS, NZS, Korea,
China, Japan);
802.11 n HT40 (5GHz): 14 dBm (USA,
Canada), 13.63 dBm (ETSI, AS, NZS, Korea,
China, Japan);
802 11 ac 80 MHz (5GHz): 14 dBm (USA,
Canada), 13.01 dBm (ETSI, AS, NZS, Korea,
China, Japan)
Modulation
Type
Bluetooth 4.1: GFSK, π/4-DQPSK, 8DPSK;
802.11 a/b/g/n/ac: DBPSK, DQPSK, BPSK,
QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Duty Cycle
Bluetooth 4.1: 1;
802.11 a/b/g/n/ac: 1
OperationMode
802.11 a/b/g/n(20M/40M) / ac
(20M/40M/80M);
Bluetooth EDR/HS/BLE
Transmission
Bit Rate
Bluetooth 4.1: 1M/2M/3M;
802.11 a/b/g/n/ac: 1M / 2M / 5.5M / 6M /
9M / 11M / 12M / 18M / 24M / 36M / 48M /
54M / MCS0~MCS9
Antenna Type
PIFAAntenna
Antenna Gain
Bluetooth 4.1: -3.92 dBi Peak
>
Legal
The product warranty can be found at www.crestron.com/warranty.
The specific patents that cover Crestron products are listed at
www.crestron.com/legal/patents.
Certain Crestron products contain open source software. for specific
information, visit www.crestron.com/opensource.
Crestron and the Crestron logo are either trademarks or registered
trademarks of Crestron Electronics, Inc. in the United States and/or
other countries. Wi-Fi is either a trademark or registered trademark
of Wi-Fi Alliance in the United States and/or other countries. Other
trademarks, registered trademarks, and trade names may be used in
this document to refer to either the entities claiming the marks and
names or their products. Crestron disclaims any proprietary interest
in the marks and names of others. Crestron is not responsible for
errors in typography or photography.
©2020 Crestron Electronics, Inc.
PRELIMINARY

Crestron TSW-70 Series Specifications

General

Brand	Crestron
Model	TSW-70 Series
Category	Touch Panel
Language	English
