Lid
Handle attachment
1.Fix the handle on the lid by screws;
2.Put the handle cover in the handle.
Handle cover
Handle
Self-tap screw(4.0x10)
A.1 x handle
B.1 x handle cover
C.4 x self-tap screw(4.0x10)
Parts List
Instructions
NOTE:The side with groove should be downwards
8
4.8*10
4.8*10
4.8*10
4.8*10
4.8*10
4.8*10
4.8*10
4.8*10
4.8*10
