INSTALLATION
6
2. Remove the top right hinge cover.
3. Undo the screws. Then remove the hinge
bracket.
4. Remove the top left screw cover.
5. Move the core cover from left side to
right side. And then lift the door and
place it on a padded surface to prevent it
from scratching.
