Ensure the freezer door is aligned
horizontally and vertically, so that the
seals are closed on all sides before
finally tightening the hinge.
10. Refit the bracket fitting the bottom hinge
pin. Replace both adjustable feet. Transfer
the lower door to the property position.
11. Move the hinge hole cover of lower door
from left side to right side.
Screw
12. Make the middle hinge reverse the
direction 180°C, then transfer it to the left
property position. Make the middle hinge
pin in the upper hole of the lower door,
then tight the bolts.
13. Place the upper door back on. Ensure the
fridge door is aligned horizontally and
vertically so that the seals are closed on
all sides before finally tightening the top
hinge.
14. Insert the hinge bracket and screw it to
the top of the unit.
15. Use a spanner to tighten it if necessary.
