Press x1: continuous light, press x2: ashing light,
press x3: colour chaser, press x4: light off.
The LED tail light comes equipped with a CR 2925 (3V) battery. To
change this battery, unscrew the four screws on the reverse of the light
with a small screwdriver. Then lift the cover, exchange the batteries and
put the cover back on. Now fasten the cover again with the four screws
(Fig. 4).
The housing of the LED rear light can be cleaned with a damp cloth.
Take the tail light off the helmet
(g. 2a). Before the rst use,
remove the safety strips from
the reverse of the LED tail light.
(Fig. 1).
To remove the LED tail light, push this upwards out of the holder (Fig. 2a).
To attach the LED tail light, push this again into the holder provided
(Fig. 2b).
The LED rear light has three different functions, each of which can be
used as desired (Fig. 3).
Fig. 1
Fig. 2a
Fig. 3
Fig. 4
Fig. 2b
