Operating Instructions
Microhmmeter Type DO5000
22
Figure 5.3.1 Diagram of different connection configurations
C1 P1 P2 C2
Connection to Cable Joint
P1 P2
Connections to Stud Terminals
C1
C2
C1 P1
P2 C2
Measurement with duplex
handspikes
Connections to Current Shunt
P1 P2
C1
C2
