Sensor detection and solenoid control specifications
Detection channels
4 per sensor
Optimal sensor detection height
1100 mm / 43-inch
Detection width at optimal height
1000 mm / 40-inch
Number of solenoid valves
4 per sensor
Nozzle spacing
250 mm / 10-inch
Max. nozzle size
06 nozzle (Grey ISO 16025)
Operating pressure
2-6 bar / 30-87 psi
PWM used frequency control range
20 - 55 Hz
PWM used Duty Cycle control range
~ 20 – 100 %
WEED-IT Quadro solenoid valve specifications
Solenoid valve specifications
Valve type
2/2 NC
Compatible with / retrofittable
to
ARAG, Hypro, TeeJet, Wilger (various types)
Check the WEED-IT Quadro PARTS LIST for the right Part
Number
Nominal constant operating
voltage
6V = 5W
Typical resistance
7.2Ω
Connection
TE SuperSeal 1.5 2-way tab with pin contacts
Ingress protection (IP)
67
Advised filtering
200 mesh / 74 (suction and press filter)
Minimum required filtering
100 mesh / 149 micron (suction and press filter)
Use hard solvable chemicals and/or mixes with care!
Use clean, properly filtered water to prevent damage!
