CROSSRC PG4L - Page 11

THREAD
LOCK
NOTE:
Get power test after assembly
finish and adjust gear meshing clearance
for make sure gear box running smooth
without noise,then process to following
assembly go on.
10
1st Gear(Low speed) 2nd Gear(Hight speed)
∅3x∅7x0.5
14102
M3x4
M2x6
11401
11102
M3x8
11106
14102
11401
11106
11102
31403
23504
41304
3
4
