CROSSRC PG4L - Page 17

11104
M2x10
∅2.5x∅6x0.4
13003
∅10x∅15x4
15004
11104
72008
72008
30201
30205
13003
41209
41237
30202
x2
x2
11103
23306
x2
11104
M2x10
11104
72003
15006
∅5x∅11x4
15006
15006
M3x4
11401
x2
∅3.8x∅9.2x0.6
13002
13002
11401
23201
23018
16
11103
M2x8
∅5x∅8x0.5
72003
15004
72008
15004
Adjust the backlash
with the Shims.
GREASE
GREASE
GREASE
GREASE
Adjust the
backlash
with the Shims.
THREAD
LOCK
13
14
