CROW ELECTRONIC ENGINEERING LTD. FW2-KP-8F - Specification: Fw2-Kp

- User Guide
8
Specification: FW2-KP
Value
FW2-KP Specification
22 keys
Keys
2 x CR132A
Battery
Graphic LCD, Gray.
Display
Arm/Disarm ,Trouble
LEDs Indications
Keys backlight ,LCD backlight
Backlight
Optional 5V-IN
Power Supply Voltage
Standby mode: Average 40uA at sleep
Operation Mode: Max 80mA Backlight +Display
on.
Current consumption
Up to 3 years
Battery life
2.5V
Low Battery Level
Trouble LED and display
Low Battery Indication
Sync signal every 1 min.
Supervision
Tamper protected against removal from the wall
Tamper
-10oC to +55oC
Operating temperature range
-20oC to +70oC
Ambient temperature, storage
FW2 Protocol
Data Protocol
GFSK
Modulation Type
8F- 868.35MHz
9F- 916.5MHz
Frequency bands
24 Bit unique code
Identification
500m At open space
RF Range
ABS
Material
L=127mm x W=127mm x H=27.5mm
Dimensions of unit
300 gr
Weight (Without Battery)
