CONNECTIONS TO GLM-100E
You can connect the GLM-100E for unipolar or bipolar powering. With unipolar powering (B+ and ground), the GLM can handle up to 120 dB SPL
without distortion. With bipolar powering (B+ and B- relative to ground), the GLM can handle up to 150 dB SPL. Not all transmitters provide bipolar
powering.
AKG TA3F 1-shield
WMS40 (PT40) 2-white
WMS400 (PT400) 3-red
WMS4000
(PT4000)
________________________________________________________
Audio-Technica Hirose HRI0- 1 and 2-shield
ATW, T31, T35, 7P-4S 3-white
T27, WT-15, 4-red
T51, T75,
ATW T21 4 pin DIN case-shield
1-white
3-red
Beyerdynamic Lemo FG331 1-shield
TS-170, TSP, 2-red
TS-600 3-white
TS-190, 4-pin binder 2-shield
TS-900 (UHF) conn. #711 3-white
4-red
Comtek 750 mono mini, 1-shield
M72, M72-B 851 micro mini, 2-white
Switchcraft TA4F, 3-red
Lemo 4-pin
Electro-Voice Switchcraft TA4F 1-red
MB2000A, 3-white
MB2500 4-shield
HME Switchcraft TA4F 1-shield
TX-425, TX-550, 2-white
TX-822 3-red
Lectrosonics Switchcraft TA5F 1and 4-shield
M185, UM190, 2-red
UM195, M187, 3-white
UM200
Lightspeed Hirose HR10- 1-shield
Technologies 7P-4S 3-white
BP Series 4-red
Nady Switchcraft TA3F 1-shield
All models 2-red
3-white
Paso MA-23, Switchcraft TA3F
MA-27 1-shield
2-white and red
3-jumper to pin 1
Peavey Switchcraft TA3F 1-red
BPX 2-shield and white
Samson Hirose HR10- 1-red
TX-3, UT-5, 7P-6S 2-white
UT-4, BT-3, CT-2 6-shield
MODEL CONNECTOR PINS
GLM-100E WIRING, 3-WIRE POWER GLM-100E WIRING, 2-WIRE POWER
MODEL CONNECTOR PINS
Samson ST-2 Hard wired 1 and 2-shield
3-red (B+)
4-white (audio)
Samson CT-3 Hard wired 1-red (B+)
2-white (audio)
3 and 4-shield
Sennheiser Sennheiser/ Ground-shield and white
SK-2012 B&K microdot Center-red
Lemosa 2-red
3-white and shield
shell-shield
Shure Switchcraft 1-shield
L-11, SC1, LX1, TA4F 2-red
U-1 (UHF), T-1 3 and 4-white
UT-1, UC-1
U1L-VA Lemo 4-pin 1-white
UC1L 2-red
4-shield
3-jumper to pin 1
Sony SMC-9 1-red
WRT-28, 2-white
WRT-820A 3 and 4-shield
Telex Switchcraft TA4F 1-shield
WT-55, WT-60, or Lemo 4-pin 2-white
WT-80, WT-150, 3-red
WT-450
TOA Mini phone plug Tip-red,
WM-340U, Sleeve-shield and white
WM-370 To prevent capsule
damage from static sparks,
solder a 3.3K resistor
between white and tip.
Vega Lemo 4-pin 1-white
F.O. 304 2-red
NYL U/3.2 4-shield
If RFI is a problem, solder a 560 pF cap. between pins 1 and 4.
Switchcraft TA4F 1-red
3-white
4-shield
X-wire TA3F 1-shield
2-white
3-red
