Crown CR-3000 - 2 Nd Channel; CROWN Installation Diagram

- 7 -
CROWN Installation Diagram
+
W
HITE
Parking Light Output
RED
12Volt Constant Input
BLACK Chassis Ground Input
YELLOW
12Volt Ignition Input
ORANGE Starter Ground Output
BROWN
VIOLET
GREEN
BLUE
Output
W
HITE/BLACK Lock
Output
RED/WHITE
2nd
Channel Output
Siren(or Horn) Output
Door Pin Input
Door Pin Input
10PIN HARNESS
2P
W
HITE
W
HITE
(Trunk)
BLUE
A
dditional device Input
Valet SW
Status LED
2P
RED
Lock
85
86
87
87a
30
START
MOTOR
* Starter Ground Output
Ignition Key
* Double Guard Shock Sensor
HORN
85
86
87
87a
30
(-)Horn: Additional relay(Programable)
* Siren Output
BAT12V
BAT12V
ANT
BLACK
LIGHT JUMPER
FCC NO. TIF1CROWN05-M
