Symbols used in the manual
Following symbols are used in the operation manual,
please remember their meanings� Correct interpreta-
tion of the symbols will allow correct and safe use of
the power tool�
Symbol Meaning
Serial number sticker:
CT ��� - model;
XX - date of manufacture;
XXXXXXX - serial number�
Read all safety regulations
and instructions�
Wear safety goggles�
Wear ear protectors�
Wear a gas mask�
Wear a gloves�
Wear a protective cloth�
Wear a protective boots�
Do not work near open re.
Disconnect the power tool
from the mains before instal-
lation or adjustment�
Movement direction�
Rotation direction�
Locked�
Symbol Meaning
Unlocked�
Minimum amount of sprayed
material�
Maximum amount of sprayed
material�
Runout time via measuring
cup�
Double insulation / protec-
tion class�
Attention� Important�
A sign certifying that the
product complies with es-
sential requirements of the
EU directives and harmo-
nized EU standards�
Useful information�
Do not dispose of the power
tool in a domestic waste
container�
Power tool designation
This power tool is designed for spraying and applying
liquid materials on a treated surface� It allows the user
to apply paints, varnishes, primers, preservatives, pro-
tective and disinfectant materials, as well as to spray
water for wetting surfaces�
Power tool components
1 Nozzle *
2 Air cap
3 Air cap position selector
4 Coupling nut
5 Spray width regulator
6 Reservoir
7 Reservoir cap
8 Spray gun unit
9 Trigger
10 Spray volume regulator
11 Locking lever
12 Cover of air lter
