PREINSTALLATION
1. Remove the old seat from the pan and clean the surface around the fixing holes.
2. Ensure the surfaces around the fixing holes are completely dry and free of any dust or debris before
beginning the installation.
3. To ensure you do not lose any dropped components in the toilet pan, place cling film over the toilet
bowl.
4. COMPLETE PRE-INSTALLATION STEPS 4, 5 & 6 BEFORE REMOVING THE HYGIENE FILM from the toilet
seat. Position the seat over your pan to ensure the shape and profile of the toilet seat matches your
toilet pan. (See Fig. 1)
5. Align the front edge of the toilet seat with the front of your toilet pan. Hold your hand at the back of
the toilet seat and using it as a pivot, raise the toilet seat. (See Fig. 2)
6. The seat should be able to rest backwards at an angle. If it cannot rest at an angle and can only
rest vertically, the seat WILL NOT function correctly. (See Fig. 3A & 3B)
7. ONLY ONCE YOU ARE SATISFIED THAT THE TOILET SEAT WILL FIT YOUR TOILET PAN SHOULD YOU
REMOVE THE HYGIENE FILM.
8. Remove the support covers (C) from the underside of the flexi fix brackets (B) to reveal the adhesive
tape and red protective film. (See Fig. 4) Note: Discard the support cover once removed, it is no
longer required.
9. Carefully peel o the red protective film from the adhesive pad on both flexi fix brackets (B).
(See Fig. 4)
TS 074 R04
2
FLEXI FIX BRACKET
SUPPORT COVER
UNDERSIDE OF
FLEXI FIX BRACKET
Fig 1.
Fig 2.
NOTE: THIS STEP IS CRUCIAL TO ENSURE
THAT THE LID AND RING ON YOUR TOILET
SEAT DO NOT FALL DOWN DURING USE!
Fig 3A.
Fig 3B.
Fig 4.
Note: Discard the support cover once
removed, it is no longer required.
C
B
To Next Page
