then press
【UP】/【DN】
key to select the value. presss
【PTT】
key or key for storing.
4. SHORTCUT OPERATION
»
1
+
2 +
3 +
4 +
5 +
6 +
7 +
8 +
9 +
10 +
11 +
12 +
13 +
Press microphone key and then press number key to fast enter following functions,
No.
Function name
Combination Key
Squelch level setting
Optional signaling setting
Scan Skip
Scan
Busy channel lockout
Frequency reverse
Time out timer
Sub channel on/off switch
Offset direction
Function Menu
Power setting.
LCD brightless
DTMF Code check
When check DTMF code, press PTT will send current DTMF code.
To revise DTMF code, press key and then press key to enter edit mode.
In DTMF check mode
input DTMF code by number keys , then press PTT to transmit the code and store.
Function list
