CRX ST0570 - Monitor Keys; Key Functions; PRIOR TO USE; U-Bracket Installation

20 pages

To Next Page

To Previous Page

Monitor Keys

1. Power On/Off

2. AV Camera switch: CAM1/CAM2/CAM3

3. M Menu

4. No function

PRIOR TO USE

U-Bracket Installation

1) Use screws to fix the U-bracket. Put the monitor into the bracket, adjust angle and lock it.

2) After finished the installation you can adjust the angle forward 30° or to backward 30°. You can adjust a suitable

angle yourself.

Wiring diagram
