Cryomech Cryocooler PT410 - Intended Use of Equipment; System Weight and Dimensions; Cooling Water Specifications

Specifications
5
-
1
Section 5: Specifications
5.1. Intended use of equipment
The Cryomech cryocooler system is used for cooling to cryogenic temperatures. Current clients
include research laboratories and universities as well as manufacturers of MRI and NMR
superconducting magnets as well as other types of equipment that require cryogenic temperatures.
5.2. Technical specifications
Following are the detailed technical specifications for the cold head and the compressor package.
CAUTION
Operation of the cryocooler in any situation that does not meet the specifications in this section will
void the warranty. If you plan to operate the system outside any of the specified conditions, contact
Cryomech, Inc.
5.2.1. System weight and dimensions
Parameter Value
Cold head weight 43 lb 19.5 kg
Cold head dimensions See cold head drawing Figure 5-8
Water cooled helium compressor
package weight
295 lb 134 kg
Water cooled helium compressor
package dimensions (L x W x H)
27 in x 19 in x 24.5 in 69 cm x 48 cm x 62 cm
High pressure flex line weight 36.3 lb 16.5 kg
High pressure flex line dimensions 1 in ID, Standard, 1/2 in Aeroquip x 3/4 in Aeroquip, 66 ft
Low pressure flex line weight 36.4 lb 16.5 kg
Low pressure flex line dimensions 1 in ID, Standard, 3/4 in Aeroquip both ends, 66 ft
5.2.2. Cooling water specifications
Parameter Value
Cooling water See Figure 5-1
Maximum inlet pressure 110 psig 7.6 bar
Alkalinity 5.8 < pH < 8.0
Calcium carbonate Concentration < 80 PPM
