Specifications
8. High and Low Pressures
Displays a running average of the suction and discharge pressure.
9. Menu Button
Allows navigation to other screens, additional controls, and system information.
10. Operating Temperatures
Displays the coolant in and out temperature, helium temperature and oil temperature.
11. RJ45 Ethernet Port
Used for remote monitoring and control of the system via Modbus TCP protocol.
12. RS232 Port
Used for remote monitoring and control of the system via SMDP or Modbus RTU protocol.
13. RS485 Port
Used for remote monitoring and control of the system via SMDP or Modbus RTU protocol.
14. Running hours
Total number of hours the helium compressor package has run, this does not include idle time.
15. Software Version
Unique number used for tracking changes to the PLC program.
16. System I/O Port
Used to remotely control the helium compressor package and monitor a limited number of its
parameters.
17. USB Port
Used to update the helium compressor package software and download recorded data from
the PLC.
18. User Feedback Text
Displays the status of the helium compressor package including errors, warnings, cold head
rpm, and date and time.
