Specifications
5-10
Cooling Water Outlet Connection
The cooling water outlet connection carries heated water away from the compressor
package after the water has been heated by cooling the compressor package during
operation. The connector thread size is 3/8 FPT (3/8” Female National Pipe Thread).
Power Cord
The power cord supplies power from the wall to the entire system.
5.5.2 Control panel description
Figure 5-6: Control panel of the compressor package
5” Capacitive Touch
Screen
Screen - ON Button
User Feedback
text
Running Hours
Menu Button
Compressor ON
Indicator Li
g
ht
Compressor ON
Button
Compressor
OFF Button
Compressor
OFF Indicator
Screen - OFF Button
RS485 Port
S
y
stem I/O Port
USB port
RJ45 Ethernet port
