Specifications
5-11
Compressor ON Button
The compressor ON button is a mechanical button used to start the compressor system.
Screen - ON Button
The screen ON button is a digital button used to start the compressor system. Its function
is the same as the compressor ON button. The button is only available on the main
screen.
Compressor ON Indicator Light
The Compressor ON indicator light is illuminated when the compressor is operating.
Compressor OFF Button
The compressor OFF button is a mechanical switch used to stop the compressor system.
Screen OFF Button
The screen OFF button is a digital button used to stop the compressor system. Its
function is the same as the compressor OFF button. The button is only available on the
main screen.
Compressor OFF Indicator Light
The Compressor OFF indicator light is illuminated when the compressor is switched off
with the Compressor Off button or when one of the compressor’s internal safety switches
has tripped.
5” capacitive touch screen
The touch screen displays system status, warnings, error messages, and the various
other operation data. It is also used to navigate through the various menus and sub
screens allowing the user to access data about the compressor system.
User Feedback text
The user feedback text tells the operator the status of the compressor including any
errors or warning which may occur.
Running hours
The running hours displays the current running(operating) hours of the compressor. (This
does not include any idle or off time.)
Menu Button
The menu button is used to navigate the system providing additional control and
monitoring.
USB Port
The USB Port can be used to download recorded data from the system.
RJ45 Ethernet Port
The RJ45 port can be used to remotely monitor and control the compressor system.
Refer to the compressor’s user guide or contact Cryomech for more information
