Specifications
5-20
F. Left & Right Arrow Button
The Left and Right Arrow Button are similar to the up and down arrow button.
J. Temperature Diode Receptacle
The temperature diode receptacle is connected to a silicon diode mounted to the cold
head’s helium condenser inside the dewar. The diode cable connects to this receptacle
and the diode connector on the cold head temperature monitor.
