Appendix A
A-3
3) Place the main beam in between the two side supports and slide the main beam mounting hardware
into place. Be sure the winch faces the side of the base assembly with the single rear post mounted
to it. Do not fully tighten the hardware down.
Note: This is step takes two people to complete.
4) Slide the main beam side supports into place resting against the main beam making sure that the
main beam is centered onto the base assembly.
Main Beam
Main Beam
Side Supports
To Next Page
