Appendix B
B-3
Figure B-4: Typical amount of lubricant
4. Apply a small amount of TFL-50® to the swivel portion of the female Aeroquip®.
Figure B-5: Apply lubricant to swivel portion
5. Apply a small amount of TFL-50® to the threaded portion of the male Aeroquip®.
Figure B-6: Apply lubricant to threaded portion
6. Use wrenches to tighten the Aeroquips® completely (see manual for instructions).
Swivel portion
Threaded portion
