UM-CV-751-19W-Q113V1 www.rackmountsales.com

< 1.3 > Installation - How to install Installation Slides

■ Fix the display drawer into the rack.

Complete the installation

Step

■ Insert the left and right rear mounting brackets into

the LCD console drawer.

Step

P. 3

Step

■ Measure the depth of the front and rear mounting rails.

■ Align each rear mounting bracket to a suitable length.

M6 screw, cage nut & cup washer x 8 are provided.
