UM-CV-751-19W-Q113V1 w ww.rackmountsales.com

< 1.3 > Installation - How to install 2 post rack brackets

Step

■ Align each rear mounting bracket to a suitable length.

■ Fix the LCD console drawer into the 2 post rack.

Complete the installation

Step

■ Insert the left and right rear mounting brackets into

the LCD console drawer in the reverse direction.

Step

P. 3

M6 screw, cage nut & cup washer x 8

are not provided.

Rear mounting

Front mounting

P. 4

Option

Model : MB-751-12
