© Copyright CSL GroupCSL960V4 17022020 PD000960-004
Model
CS2369 2G/GSM
CS2389 2G/GSM, 3G/UMTS, 4G/LTE
Dimensions 172mm (h) x 72mm (w) x 20mm (d)
Weight 149g including aerial
Temperature -20°C to + 60°C transit, -4°C to +40°C operating
Humidity 0-80% non-condensing
Warranty 2 years
Radio Technology GSM, UMTS, LTE, Wi-Fi 2.4Ghz (depending on version)
Battery 3.7 Volt 1000mAh
Charger 5 Vdc micro USB plug-top charger or equivalent
RSSL EXPLANATION
To ensure that a consistent approach is used to all Radio Access Technologies (RAT) - such as 2G, 3G
and 4G - a new, more accurate method for calculating percentage of the signal strength has been
introduced. The RSSL is not based on CSQ readings alone provided by the radio module, but is calculated
from the raw data received from the network readings. The value is mapped through the whole range
and is consistent across each RAT. The value calculation includes both signal strength and signal quality
measurements.
The example of such mapping for a 3G cell is:
RSCP: -80 dBm
RSRQ: -4 dB
CSQ: 19
ECIO: 12
PART NUMBER CS2369 CS2379 CS2389 CS2389-NA CS2389-AU
4G Bands (MHz)
800 (B20)
900 (B8)
1800 (B3)
2100 (B1)
2600 (B7)
700 (B12/B13)
850 (B5)
1700 AWS (B4)
1900 (B2)
700 (B28)
1800 (B3)
2600 (B7)
3G Bands (MHz)
900 (B8)
2100 (B2)
900 (B8)
2100 (B2)
850 (B5)
1900 (B2)
2G Bands (MHz)
850 (B5)
900 (B8)
1800 (B3)
1900 (B2)
900 (B8)
1800 (B3)
900 (B8)
1800 (B3)
Wi-Fi
2.4Ghz
2.4Ghz
FREQUENCY BAND
SPECIFICATIONS
SUPPORT
For more information on the Signal Analyser or other CSL products please contact
CSL Technical Support:
UK Tel: +44 (0)1895 474 444
Ireland Tel: 1800 855 695
Email: support@csl-group.com
Hours: 08.30 to 18.00 weekdays, 10.00 to 16.00 Saturday
Visit www.csl-group.com for the latest copies of all manuals.
CERTIFICATIONS
International Radio Approval
The CS2369/CS2379/CS2389 Signal Analyser incorporates an independently tested and approved
4G/3G/2G radio module that meets the requirements of European radio communication standards
Approval Authority: CE1909
