This section provides basic information to enable you to set up your Signal Analyser quickly.
AERIAL
1. Connect the aerial on top of the device
POWERING UP YOUR DEVICE
1. Make sure the battery is fully charged using the Micro USB port on the bottom of the device
(this typically takes 2 hours). The device will not operate correctly for surveys or monitoring while a
USB is connected.
2. Once power is connected the device will turn on
The first ever power up may take 2-3 minutes as the unit will be doing a background network
search to establish the available networks in your location
FITTING A SIM
A SIM is only required when using Monitor Mode and not when performing single or multiple network surveys
1. Ensure your device is powered down and insert the SIM into the SIM slot on the bottom right hand
side of your Signal Analyser. To remove the SIM, use a pen to depress before detaching. When a SIM
is inserted a SIM Icon will be displayed in the top left hand corner of the screen
If you wish to use a Micro/Nano SIM you will need to use the SIM carrier supplied
2. Place the SIM inside the carrier and push this into the SIM slot on the bottom right hand side of your
Signal Analyser. To release use a pen to depress the SIM carrier and then detach
HELP TEXT
1. Press and hold (for 3 seconds) the icon you would like explaining. A pop up box will then show with
the description
2. To close the pop up box press the X in the top right hand corner
QUICK GUIDE
5
HELP MESSAGE
Perform a cellular survey on all
available networks.
Figure 2 - Help Text
