All-In-One ESS Energy Storage System
Step 1:
Step 2:
Step 3:
Step 4:
Press the DC switch button, then press the AC switch button, and the display will light up
Turn on the external PV switch.
（
If there is a PV external switch
）
Turn on the external grid switch.
（
If there is a external grid switch
）
If backup load is applied, turn on the external Backup switch.
NOTE:
the Backup switch is only used when a backup load is applied.
3.2 Switch Off
Step 1:
Step 2:
Step 3:
Step 4:
Press the AC switch button, then press the DC switch button until the display is
off. Turn off the external grid switch.
If backup load is applied, turn off the external backup
switch. Turn off the external PV switch on the cable box.
3.3 AC Input/Output Connection
CAUTION: Before connecting to AC input power source, please install a separate AC breaker between
inverter and AC input power source. This will ensure the inverter can be securely disconnected during
maintenance and fully protected from over current of AC input. The recommended spec of AC
breaker is 32A for 1KW/3KW.
CAUTION: There are two terminal blocks with ‘IN’ and ‘OUT’ markings. Please do NOT mis-
connect input and output connectors.
WARNING: All wiring must be performed by a qualified personnel.
WARNING: It’s very important for system safety and efficient operation to use appropriate cable for
AC input connection. To reduce risk of injury, please use the proper recommended cable size as
below.
Suggested cable requirement for AC wires
Please follow below steps to implement AC input/output connection:
Before making AC input/output connection, be sure to open DC protector or disconnector first.
Remove insulation sleeve 10mm for six conductors. And shorten phase L and neutral conductor N 3
mm. Insert AC input/output wires according to polarities indicated on terminal and tighten the
terminal screws.
Be sure to connect PE protective conductor first.
9
Model Gauge Torque Value
1KW 1*16AWG 05-0.6 Nm
3KW 1*12AWG 1.2-1.6 Nm
5KW 1*8AWG 1.4-1.6 Nm
