English | 132 610 A12 214 • 22.7.09
Operation
Initial Operation
f Protect the remote control against moisture
and direct sunlight.
f Do not subject the remote control to extreme
temperatures or variations in temperature.
As an example, do not leave it in vehicles for longer
periods. In case of large variations in temperature,
allow the remote control to adjust to the ambient
temperature before putting it into operation.
The remote control remains ready for operation as
long as batteries with sufficient voltage are inserted.
Set up the rotational laser level in such a manner that
the signals of the remote control directly reach the
receiption lens on the rotational laser level (for this,
see the operating instructions of the rotational laser).
When the remote control cannot be pointed directly
against a receiption lens, the working range is
reduced. By reflecting the signal (e.g. against walls),
the working range can be improved even for indirect
signals.
After pressing a button on the remote control, the illu-
minated operation indicator 29 indicates that a signal
was sent out.
Switching the rotational laser on/off with the remote
control is not possible.
Operating Modes
For detailed information of the rotational laser level
functions, see the operating instructions of the rota-
tional laser level (see “Rotational Laser Level”, from
page 5 on).
Rotation, Line and Point Operation
By pressing the function-mode button 30, you can
change between rotational operation with two aper-
ture angles and point operation.
Rotating the Laser Point/Laser Line in the Rota-
tional Plane
The laser point or the laser line can be rotated in steps
by 360° within the rotational plane. Press button 31
to rotate in clockwise direction, and button 34 to
rotate in anticlockwise direction. Pressing and holding
the buttons increases the speed of the rotation head
in the desired direction.
Maintenance and Service
Maintenance and Cleaning
Keep the remote control clean at all times.
Do not immerse the remote control into water or other
fluids.
Wipe off debris using a moist and soft cloth. Do not
use any cleaning agents or solvents.
If the remote control should fail despite the care taken
in manufacture and testing, repair should be carried
out by an authorised customer services agent for
Bosch power tools. Do not open the remote control
yourself.
After-sales Service and Customer
Assistance
For addresses, see “After-sales Service and Cus-
tomer Assistance”, page 11.
Disposal
For disposal of the measuring tool, please observe the
information under “Disposal”, page 11.
Subject to change without notice.
