CTM HS-328 - Specification

Instruction BookletHS-328
SPECIFICATION
14
*Subject to change without notice. (Issue B 24/05/2016 )
SPECIFICATION
Overall Length
Overall Width
Overall Height
Front Wheels
Rear Wheels
Weight W/ Batteries
Weight Of Heaviest Piece
Max. Speed
Weight Capacity
Ground Clearance
Grade Climbable
Curb Climbable
Turning Radius
Suspension
Brake
Seat Type
Seat Width
Motor Size
Battery Size
Battery Weight
Travel Range
Battery Charger
Electronics
1120 mm / 44"
590 mm / 23"
935 mm / 37"
225 mm / 9"
225 mm / 9"
55 kg / 121 lbs
17.4 kg / 38 lbs
8 kmph / 5 mph
136 kg / 300 lbs
52 mm / 2"
8 degree
40 mm / 2"
1450 mm / 57"
Rear (Option)
Electro-Mechanical
Swivel Light Weight Foldable
460 mm / 18"
250W, 4000 r.p.m
(2) 12V. 22Ah
15.5 kg / 34 lbs
17.5 km / 11 Miles
3A Off Board
On / Off Key Switch,
Battery Level Indicator,
Speed Control Knob
