General| Panel type | TFT |
|---|---|
| Color depth | 8 bit |
| Pixel pitch | 0.42975 x 0.42975 mm |
| Screen shape | Flat |
| Response time | 8 ms |
| Backlight type | Direct LED |
| Display diagonal | 74.54 \ |
| Surface hardness | Mhos 7 |
| Touch technology | Multi-touch |
| Display brightness | 350 cd/m² |
| Display glass type | Tempered glass |
| Display technology | LCD |
| Native aspect ratio | 16:9 |
| Maximum refresh rate | 60 Hz |
| Contrast ratio (typical) | 4000:1 |
| Display number of colors | 1.073 billion colors |
| Display diagonal (metric) | 189.3 cm |
| Number of simultaneous touchpoints | 20 |
| Certification | WEEE |
| Product color | Black, Grey |
| Glass thickness | 4 mm |
| Cables included | AC, HDMI, USB, USB Type-C |
| Audio input | Mini Jack |
| USB hub version | 3.2 Gen 2 (3.1 Gen 2) |
| DisplayPort version | 1.2 |
| HDMI ports quantity | 3 |
| USB upstream port type | USB Type-C |
| USB Type-A downstream ports quantity | 5 |
| AC input voltage | 100 - 240 V |
| Power supply type | AC |
| AC input frequency | 50 / 60 Hz |
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 120 W |
| Panel mounting interface | 800 x 600 mm |
| On Screen Display (OSD) languages | DEU, DUT, ENG |
| Package depth | 225 mm |
| Package width | 1873 mm |
| Package height | 1186 mm |
| Package weight | 72600 g |
| Placement supported | Horizontal |
| Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 2 |
| Built-in camera | No |
| RMS rated power | 80 W |
| Sustainability certificates | CE, RoHS |
Weight and Dimensions| Depth (without stand) | 104 mm |
|---|---|
| Width (without stand) | 1727 mm |
| Height (without stand) | 1020 mm |
| Weight (without stand) | 61700 g |
