Please consult below checklist for all the components.
1. what’s in the box
2. meet the doorbell
User GuideUSB Cable
Video Doorbell
Adhesive Tape
3. Meet the chime
Speakers
Reset
2
1
LED Indicator
USB Port (Type-A/M)
3
4
1
3
2
4
Indoor Chime Screw & Tools
- 1 -
2MP camera
Motion sensor
Speakers
Doorbell button
LED indicator
Charging indicator
Micro-USB port
Reset hole
Security screw hole
Microphone
Power contacts
Hardwire terminals
Micro-SD card slot
18650 Battery pack
Security screw
Mounting screw holes
3
2
1
4
6
5
8
7
10
9
12
11
13
15
16
14
12
11
13
14
2
1
4
5
10
6
7
8
9
3
1615
