CTS HET-3012 SERIES - LED Description; Fiber Transceiver Information; Technical Specifications; Contact Information

LED Description
5. Technical Specifications
Standards:
IEEE 802.3, 802.3u, 802.3ab, 802.3z
Interface:
10/100/1000Base-T RJ-45 Port
100Base-FX/1000Base-X FO Port
Operation LED:
Power, FO Link/ACT, TX Link/ACT
Power:
DC 12V, 1A
Power
Consumption:
Minimum: DC 1.7W / AC 2.4W
(Copper & F/O not connected)
Maximum: DC 3.36W/AC 4.57W
(Copper & F/O traffic presents)
Shipping
Weight:
1KG
Dimensions:
160X110X45mm (WxDxH)
Temperature:
Operating: 0~50
o
C
Storage: -20~60
o
C
Humidity:
5%~90% RH
Emission:
Electrical: UL, CSA
EMI: FCC Class A, CE
*Please contact us for further reports and updates.
Media:
TP
EIA/TIA-568 CAT 5e, 100M
Fiber
50/125, 62.5/125um multi-mode fiber
9/125, 10/125um single-mode fiber
Fiber Transceiver Information
1000M
Multi-Mode
TYPE
BTFC
BTFT
Connector Type
SC
SC
Wavelength
850nm
850nm
Typical Distance
500m
500m
Min TX PWR
-9.5dBm
-9.5dBm
Max TX PWR
-4.0dBm
-4.0dBm
Sensitivity
-18.0dBm
-18.0dBm
Link Budget
8.5dB
8.5dB
Single-Mode
TYPE
BTFC(SM-10)
BTFC(SM-20)
BTFC(SM-30)
Connector Type
SC
SC
SC
Wavelength
1310nm
1310nm
1310nm
Typical Distance
10Km
20Km
30Km
Min TX PWR
-9.5dBm
-5.0dBm
-5.0dBm
Max TX PWR
-3.0dBm
3.0dBm
3.0dBm
Sensitivity
-20.0dBm
-24.0dBm
-24.0dBm
Link Budget
10.5dB
19.0dB
19.0dB
Wave-Length WDM
TYPE
W2A(SM-10
)
W2B(SM-10
)
W2A(SM-20)
W2B(SM-20
)
Connector Type
SC
SC
SC
SC
TX Wavelength
1310nm
1550nm
1310nm
1550nm
RX Wavelength
1550nm
1310nm
1550nm
1310nm
Typical Distance
10 Km
10 Km
20 Km
20 Km
Min TX PWR
-10.0dBm
-9.0dBm
-6.0dBm
-6.0dBm
Max TX PWR
-3.0dBm
-3.0dBm
0dBm
0dBm
Sensitivity
-22.0dBm
-22.0dBm
-23.0dBm
-23.0dBm
Link Budget
12.0 dB
13.0 dB
17.0 dB
17.0 dB
100M/1000M Dual Speed
Wave-Length WDM
TYPE
W2A(SM-10
)
W2B(SM-10
)
W2A(SM-20)
W2B(SM-20
)
Connector Type
SC
SC
SC
SC
TX Wavelength
1550nm
1310nm
1550nm
1310nm
RX Wavelength
1310nm
1550nm
1310nm
1550nm
Typical Distance
10 Km
10 Km
20 Km
20 Km
Min TX PWR
-9.0dBm
-9.0dBm
-8.0dBm
-8.0dBm
Max TX PWR
-3.0dBm -3.0dBm -2.0dBm -2.0dBm
Sensitivity
-20.0dBm -20.0dBm -23.0dBm -23.0dBm
Link Budget
11.0 dB 11.0 dB 15.0 dB 15.0 dB
NOTE: Specifications may change without prior notice.
HET-3012 SERIES
10/100/1000BASE-T TO
1000BASE-X MEDIA
CONVERTER
User’s Guide
Version 0.95
Contact Information
Connection Technology Systems INC (CTS)
18F-6, No.79, Sec.1, Xintai 5th Rd., Xizhi Dist.,
New Taipei City 221, TAIWAN, R.O.C.
TEL: +886 2 26989661 FAX: +886 2 26989662
E-Mail: info@ctsystem.com
LED
Color
Function
Power Green Lit when power is available.
TX
Link/Act
Off
Port link is down.
Green
Lit when TP port works in 10M and
100M.
Green
Blinking
Blink when TP traffic is present
(under 10M and 100M).
Orange
Lit when TP port works in 1000M.
Orange
Blinking
Blink when TP traffic is present
(under 1000M).
FO
Link/Act
Off
Fiber link is down.
Green
Lit when Fiber port works in 100M.
Green
Blinking
Blink when Fiber traffic is present
(under 100M).
Orange
Lit when Fiber port works in 1000M.
Orange
Blinking
Lit when Fiber traffic is present
(under 1000M).
