Specifications
Note: Specifications are subject to change without notice.
Color Picture Tube 51 cm / 21" (20" viewable screen size) diagonal
measurement, 90 degree deflection, dot type black
matrix anti-glare, anti-reflection, anti-static, medium
short persistence phosphor
Dot Pitch 0.26 mm
Input Signal Video: 0.7 Vp-p/75 ohm, analog positive
Sync: Separate Sync.: TTL Level
Horizontal Sync.: positive/negative
Vertical Sync.: positive/negative
Composite Sync.: TTL Level, positive/negative
: Composite Sync, on green video
0.3V-pp Negative
Scan Frequency Horizontal: 30 to 95 kHz automatically
Vertical: 50 to 160 Hz automatically
Display Area Horizontal 390 mm (adjustable)
Vertical 290 mm (adjustable)
Max. Resolution Horizontal 1600dots,
Vertical 1200 lines, non-interlaced
Display Colors Analog input, unlimited colors
Dot Frequence 202.5 MHz
Misconvergence Center 0.3 mm, Corner 0.4 mm maximum
Plug & Play DDC 1 / DDC 2B
USB Down stream port x 4
Per down stream port support current 500mA (Max.)
Power Supply 100-120 VAC/200-240 VAC, 50/60 Hz
(automatically)
Power Consumption 120W max.
Dimensions 510(W) x 506.2(H) x 544.7(D) mm
Weight 35 kgs(G.W.), 30kgs(N.W.)
Environment Operating Temperature: 0°C to 35°C
Consideration Humidity 20% to 80%
Storage Temperature:20°C to 60°C
Humidity 10% to 90%
TECHNICAL INFORMATION
