48" Spindle Assembly
- Parts List for Figure 4
Ref.
No. Part No. Description Qty.
1 00008495 Capscrew, 3/8-16 x 1-3/4 1
2 00022560 Hex Nut, 3/8-16, Flange Lock 25
3 00034167 Capscrew, 3/8-16 x 5.00 1
4 00060078 Grease Fitting, 1/4-28 x 3/16 1
5 01000199 Extension Spring, 1.0 OD x 5.00 1
6 01000302 Shoulder Screw, 7/16-14 1
7 01000364 Hex Carriage Screw, 3/8-16 x 1.75 1
8 01000369 Capscrew, 3/8-16 x 1.25 9
9 01000372 Carriage Bolt 3/8-16 x .75 9
10 01000379 Hex Nut, 7/16-14 1
11 01000380 Nut, 3/4-16, Hex Flange 3
12 01000387 Idler Spring 1
13 01000389 Lock Washer, 7/16 1
14 01000392 Flat Washer, .781 ID x 2.00 OD x .105 3
15 01000399 Belt, A Section x 107.3 1
16 01000643 Carriage Bolt, 3/8-16 x 1 4
17 01009906 Carriage Bolt, 3/8-16 x 5.0 1
18 01000723 Flat Washer, .406 ID x 1.0 OD x .105 14
19 01002564 Spacer, .76 ID x 2.00 OD x .477 4
20 01003245 Spacer, .39 ID x .625 OD x 2.75 1
21 01005692 Spring Tension Rod Assembly 1
22 01004065 Spacer, .405 x .75 x 3.875 1
23 01004081 Flat Pulley 1
24 01004101 Idler Pulley, 4.06 OD 1
25 01004118 Shoulder Screw, .50 x .27 Lg., 3/8-16 1
26 01004129 Spacer, .385 ID x .75 OD x .875 2
27 01004185 Capscrew, 3/4-16 x 6.50 1
28 01004415 Spacer, .760 ID x 2.00 OD x 0.9 3
29 01004772 Hi-Lift Blade, 16.5, 0.756 ID 3
30 01005103 Idler Arm Assembly, Flat Top Bearing 1
01000308 Bearing Sleeve 2
31 01005202 V-Pulley, 4.75 OD 1
32 01006469 Idler Arm Mounting Plate 1
33 01006440 Spindle Support Plate 2
34 01006442 RH Spindle Support PLate 1
35 01006468 Idler Arm Mounting Bracket 1
36 01006470 Housing Assembly 3
37 01006533 Spacer, .76 ID x 1.25 OD x .44 6
38 01006534 Spindle Spacer 6
39 01006535 V-Pulley, 5.0 OD 3
40 01006590 Capscrew, 3/4-16 x 5.50 2
41 01006760 Idler Arm Assembly, Deck Spindle 1
01000308 Bearing Sleeve 2
42 00050441 V-Belt, B-Section 1
43 01001539 Spacer, .39 ID x .875 OD x 1.100 1
44 01002750 Carriage Bolt, 3/8-16 x 3.5 1
45 01005314 Washer, 7/16 ID x 1.75 OD x .25 1
46 756_0542 Pulley, 1.0 OD 1
47 00012226 Grease Fitting, 1/4-28, 90 degree 1
