13
44" Control Assembly
- Parts List for Figure 5
Ref.
No. Part No. Description Qty.
1 00012382 Hex Cap Screw, 5/16-18 x 1-1/2 2
2 00083192 Idler Washer 1
3 00008495 Capscrew, 3/8-16 x 1-3/4 1
4 01000372 Carriage Bolt, 3/8-16 2
5 00012165 Nylock Nut, 5/16-18 3
6 01008620 Self Tapping Screw, 5/16-18 x 3/4 5
7 01000629 Self Tapping Screw, 1/4-20 x .75 9
8 00013595 Parking Brake Grip 1
9 00021797 Spring, .85 OD x 1 Lg 1
10 00022560 Hex Nut, 3/8-16 Flange Lock 5
11 01000872 Flat Washer, 1.25 x .411 x .100 1
12 01000628 Screw, 1/4-20 x 1/2 20
13 01000635 Hex Nut, 5/16-18 Flange Lock 4
14 -- -- --
15 01002634 Shoulder Screw, 3/8-16, .5 x 2.345 2
16 01002753 Groment, 2.5 OD x 1.0 Lg 2
17 01002766 Hex Nut, 1/4-20 Flange Lock 3
18 01002772 Spacer, .375 x .50 x 1.02 1
19 01003563 U-Nut, 5/16-18 2
20 01008464 Foot Rest Bracket 1
21 01008198 Left Hand Brake Cable (not shown) 1
22 01008199 Right Hand Brake Cable (not shown) 1
23 01008482 Control Housing Weldment 1
24 01008413 Seat Adjust 1
25 01010006 Left Hand Control Console 1
26 01010007 Right Hand Control Console 1
27 01008487 Parking Brake Lever 1
28 01008488 Brake Cable Bracket 1
29 01008491 Front Tank Mounting Bracket 1
30 01008528 Lapbar Stop Bracket 2
31 01008539 U-Nut, 1/4-20 4
32 01008572 Battery Edge Trim 4
33 01008583 Seat Mounting Bracket 2
34 00012166 Hex Nut, 5/16-18 2
35 01000960 Washer, .325 x .930 x .045 2
36 01006528 Abrasive Foot Pad 1
