R.
S
INGLE
PEDAL
BRAKE
LOCK
A
WARNING
The
hydrostatic
transmission
will
not
hold
the
tractor
on
a
hill.
In
a
short
period
of
time
(depending
on
the
steepness
of
the
hill)
the
oil
will
drain
from
the
transmission
and
allow
the
tractor
to
roll
downhill.
To
avoid
an
accident
and/or
possible
injury,
engage
the
single
pedal
brake
lock.
Always
engage
the
single
pedal
brake
lock
when
dismounting
the
tractor.
To
lock
the
brake,
the
turning
brake
pedals
must
be
locked
together
to
provide
brak¬
ing
to
both
rear
wheels.
Refer
to
TURNING
BRAKE
LOCK."
Depress
single
brake
pedal
and
place
the
sin¬
gle
pedal
brake
lock
in
the
engaged
position.
(See
Figure
9.)
To
disengage
the
lock,
press
down
on
the
pedal,
lift
the
lock
up
and
place
it
in
the
disengaged
position.
1.
Single
Brake
Pedal
2.
Single
Pedal
Brake
Lock
S.
S
INGLE
BRAKE
PEDAL
T.
H
YDRAULIC
LIFT
CONTROL
LEVER
I^NOTE
The
engine
must
be
running
in
order
to
operate
the
hydraulic
lift.
The
hydraulic
lift
control
lever
controls
the
raising
and
lowering
of
equipment
used
with
the
tractor,
if
installed.
The
control
lever
is
spring
loaded.
To
raise
the
equipment,
pull
up
on
the
lever.
To
lower
the
equipment,
push
down
on
the
lever.
(See
Figure
10.)
U.
T
HROTTLE
CONTROL
LEVER
This
lever
controls
the
sipeed
of
the
engine.
When
set
in
a
given
position,
it
will
maintain
a
uniform
engine
speed.
(See
Figure
10.)
NOTE
When
using
power
take-off
operated
equip¬
ment,
best
performance
is
achieved
with
the
throttle
lever
in
the
"FAST"
position.
NOTE
Do
not
rest
your
foot
on
the
single
brake
pedal
while
driving
the
tractor
as
this
would
cause
the
speed
control
lever
to
return
to
the
"N"
position.
The
single
brake
pedal
must
be
pressed
all
the
way
down
to
activate
the
safety
starting
switch.
When
the
single
brake
pedal
is
in
the
depressed
position
it
automaticaily
moves
the
speed
control
lever
to
the
"N"
position.
(See
Figure
9.)
This
symtrol
shows
slow
("IDLE")
posi¬
tion.
This
symbol
shows
fast
position.
V.
F
RONT
POWER
TAKE-OFF
(PTO)
CONTROL
SWITCH
The
power
take-off
(PTO)
control
switch,
which
is
located
on
the
left
side
of
the
instrument
panel,
operates
an
electric
clutch.
(See
Figure
3.)
This
elec¬
tric
clutch
controls
the
engagement
("ON”)
or
disen¬
gagement
("OFF")
of
the
front
PTO.
11
