Cub Cadet 221 HP Illustrated Parts Manual

15
370-JU-11 Crankcase
Ref.
Part Number Description
47 951-12111 Piston Ring Set
48 951-11632 Piston Pin Snap Ring
49 951-12007 Piston
50 951-11633 Piston Pin
51 710-04915 Bolt M6×12
52 951-11113 Air Shield
53 951-11573 Connecting Rod Assembly
54 951-11356 Governor Arm Shaft
55 736-04461 Washer 5.2×1.9
56 951-11902 Governor Seal
57 714-04074 Cotter Pin
58 951-11575 Camshaft Assy.
59 951-11369 Radial Ball Bearing, 6205
60 951-12102 Crankshaft Kit
(Incl.59-61,71,79)
61 951-10307 Woodru Key
62 951-11576 Governor Gear/Shaft Assembly
63 715- 04092 Dowel Pin 7×14
64 715-04089 Dowel Pin 9×14
65 951-11371 Crankcase Cover Gasket
66 951-12125 Cover Comp, Left Crankcase
67 710-04932 Bolt M8×32
68 951-11283 Oil Fill Plug Assembly
Ref.
Part Number Description
70 951-11577 O-Ring 15.8×2.5
71 951-1136 8 Oil Seal, 25×41.25×6
73 951-11381 Oil Fill Tube O-Ring
74 951-11913 Oil Fill Tube Assembly
75 951-11904 Dipstick O-Ring
76 951-12482 Dipstick Assembly
77 951-12103 Crankcase Kit
(Incl.56,59,71,77,79)
78 951-12514 Oil Drain Plug
79 951-11370 Oil Seal 25×41.25×6
109 753-06684 Oil Drain Tube Kit (Optional)
952Z370-JU-11 Complete Engine
951-12026 Gasket Kit - External
(Incl.6,22,27-29,35)
951-1124 6 Crankcase Cover Kit
(Incl.59,65-67,69-71)
951-12121 Gasket Kit - Complete
(Incl.6,22,27-29,35,40,
55,56,65,71,79)
751-12513 Short Block
(Incl.6,22,27,28,41,43,44,47-50,
53-60,62-67,69-71,77-79)
