Cub Cadet 221 HP Illustrated Parts Manual

5
Shroud, Chute & Handle (Model 221 HP)
Ref.
Part Number Description
1 736-04576 Flat Washer, .28 x 1.5 x .075
2 747-05327B Auger Bail
3 710-0451 Carriage Bolt, 5/16-18 x .750
4 710-05108 Hex Washer Screw, 1/4 x .750
5 712-04063 Flange Lock Nut, 5/16-18
6 712-04064 Flange Lock Nut, 1/4-20
7 731-08274 Chute Ring
8 720 - 04122 Wing Knob, 5/16-18
9 731-04426A Upper Chute
10 731-07644 Chute Handle
11 931-07753A Lower Chute
12 932- 04111 Chute Adjustment Spring
13 749-04703B Upper Handle
14 710-0895 Screw, Hi-Lo:1/4-15, 0.75
15 925-04031A Ignition Switch Assembly
16 710-04669 Hex Washer Screw, 10-16 x .625
17 710-0599 Hex Washer Screw, 1/4-20 x .500
18 731-07725 Bottom Cover
19 731-07830A Top Cover
20 710-04998 Carriage Screw, 5/16-18 x 1.00
21 710-05348 Eye Bolt, 1/4-20
22 720-0279 Handle Knob
23 738-04419A Shoulder Screw, 1/4-20 x .375 x .148
