Cub Cadet 221 HP Illustrated Parts Manual

7
Shroud, Chute & Handle (Model 221 LHP)
Ref.
Part Number Description
1 710-05163 Carriage Bolt, 5/16-18 x 2.5
2 712-04063 Flange Lock Nut, 5/16-18
3 731-07651 Chute Control Panel
4 731-07654A Cable Handle Guide
5 731-07656 Chute Control Panel, Inner
6 731-07868 Cable Clip
7 946-04722 Cable
8 750-05414 Spacer, .325 ID x .496 OD x 1.34
9 631-04526P Chute Control Assembly
10 710-04352 Screw, #6 x .375
11 710-04353 Screw, #8 x 1.00
12 731-08018 Chute Rod
13 732-04789 Spring, .460 OD x 1.469
14 684-04350 Joint Block Assembly
15 715- 0150 Roll Pin, 3/16 Dia. x 1.1 LG.
16 684-04383 Indicator Bracket Assembly
17 925-04031A Ignition Switch Assembly
18 710-0262 Carriage Bolt, 5/16-18 x 1.00
19 710-0451 Carriage Bolt, 5/16-18 x .75
20 710-05108 Hex Washer Screw, 1/4 x .750
21 710-05179A Screw, #8-32 x .875
22 710-0599 Hex Washer Screw, 1/4-20 x .500
23 710-0895 Screw, Hi-Lo:1/4-15, 0.75
24 712-04063 Flange Lock Nut, 5/16-18
25 712-04064 Flange Lock Nut, 1/4-20
26 712- 04035 Hex Lock Nut, #8-32
27 714-04003 Cotter Pin
28 715-04095 Pin, .156 x .875
29 717-04941 Bevel Gear, 40T/11T
Ref.
Part Number Description
30 717- 0 4940 Spur Gear, 35T
31 917-04844B Bevel Gear, 95T
32 720 - 04122 Wing Knob, 5/16-18
33 731-04427A Upper Chute
34 731-06451 Cable Guide
35 731-07708 Chute Plug
36 931-07753A Lower Chute
37 731-07957 Chute Cover
38 720-04174 Grip, 1.18 x 3.33
39 710-04669 Hex Washer Screw, 10-16 x .625
40 731-07721A Top Cover
41 731-07725A Bottom Cover
42 736-04161 Flat Washer, .75 x 1.00 x .06
43 941-0475 Plastic Bushing, .380 ID
44 747-05299A Chute Rod
45 784-5594 Cable Bracket
46 790-00471 Gear Retainer Bracket
47 790-00416 Gear Mounting Plate
48 931-04504 Handle Panel Assembly
49 731-07784 Handle Panel Lens
50 710-04998 Carriage Screw, 5/16-18 x 1.00
51 710-05348 Eye Bolt, 1/4-20
52 720-0279 Handle Knob, 1/4-20
53 725- 0157 Cable Tie
54 725-1629 Lamp
55 738- 04419A Shoulder Screw, .375 x .148 x 1/4-20
56 747-05327B Auger Bail
57 749 -04693B Upper Handle
— 925- 04139* Harness Assembly
* Not Shown
