Cub Cadet 221 HP Illustrated Parts Manual

9
Drive System & Auger Assembly
Ref.
Part Number Description
1 684-04168 Idler Pulley Assembly
2 684-04398 Frame
3 984-04393 Auger Assembly Mount
4 929-0071A 3-Prong Extension Cord
5 753-06469
Auger Replacement Kit (Inc. 2 Pad-
dles and 12 Hex Washer Screws)
6 790-00427 Center Auger Bracket
7 710-0134 Carriage Screw, 1/4-20 x .62
8 710-0778 Hex Screw, 1/4-20 x 1.50
9 710-0627 Hex Lock Screw, 5/16-24 x .750
10 710-0642 Hex Washer Screw, 1/4-20 x .750
11 710-0599 Hex Washer Screw, 1/4-20 x .500
12 710- 0817 Hex Washer Screw, 5/16-18 x 1.250
13 710-0895 Hex Washer Screw, 1/4-15 x .750
14 710-04484 Hex Washer Screw, 5/16-18 x .75
15 712-04065 Flange Lock Nut, 3/8-16
16 936- 0192 Flat Washer, .535 x .930 x .090
17 712-04064 Flange Lock Nut, 1/4-20
18 718-04836 Pulley Hub
19 931-07626A Chute Adapter
20 731-08171 Shave Plate
21 731-07737A Belt Cover
22 732-04748 Extension Spring, .70 x 3.035
23 710-05183 Hex Screw, 5/16-24 x 1.25
24 738-04456 Shoulder Bolt, 5/16-24 x .496 x 2.18
25 741-04517 Ball Bearing, .500 x 40mm x 12mm
26 946-04701 Clutch Cable
27 747-05360A Drive Cable Wire Support
Ref.
Part Number Description
28 748-0234 Shoulder Spacer
29 749-04810 Lower Handle
30 750-04571 Shoulder Spacer, .260 x .785 x .538
31 750-04758 LH Auger Spacer
32 750-05393 RH Auger Spacer
33 790-00444 RH Auger Plate
34 790-00445 LH Auger Plate
35 790-00457 Bearing Cup
36 790-00461 Idler Bracket
37 790-00426 Cable Idler Bracket
38 726-0299 Push Cap, 1/2
39 634-04347 Wheel, 8”
40 750 - 05417 Sleeve Spacer, .525 x .78 x 1.00
41 747-05513 Gas Tank Wire Support
42 751-10487A Fuel Cap
43 751-11648 Fuel Tank
44 731-07664 Choke Extension Lever
45 710-0654A Hex Washer Screw, 3/8-16 x 1.000
46 912-0702 Flange Nut, 7/16-20
47 710-05339 Hex Cap Screw, 5/16-24 x .75
48 954-04050 Belt, .500 x 35.06
49 956-0416B Pulley Half, .625 x 2.25
50 756-04443 Pulley, 1/2 x 6.00
51 726-0233 Push Nut
52 710-05058 Hex Washer Screw, 1/4-20 x .750
53 952Z265-JU† Replacement Engine
952Z370-JU†† Replacement Engine
† Model 221 HP
†† Model 221 LHP
