7
SPECIFICATIONS
Engine: 19HP Kawasaki, 20 & 24HP Honda, 23 & 25HP Kawasaki, 25 &
27HP Kohler, 28HP Kohler E.F.I., 28 & 33HP Generac
Type: Vertical air cooled V-Twin
Air Cleaner: Paper Element
Lube System: Pressurized with oil filter
Starter: 12-volt electric
Traction Drive: Engine to two variable-speed hydraulic wheel motors on each
drive wheel
Hydraulic Tank: 10 quart capacity, One quart filter
Cutter Deck;Drive: 48", 54", 60", & 72” Belt Driven
Clutch: Electric
Deck Lift: Hand lever w/pin lock for height adjustment
Cutting Height: 1-1/2" to 5"
No. of Blades 3, belt-driven, power take-off from engine
Controls: Engine ignition and start switch; throttle; choke; left and right
steering levers; electric blade clutch switch; parking brake; mower
deck lift
Parking Brake: Mechanical linkage attached to the brake handle
Front Caster Wheels: 48” deck, 13 x 5.0 x 6; 54”, 60”, & 72” deck, 13 x 6.50 x 6
Tire Pressure: 8-10 psi Rear, 20-25 psi front caster
Drive Wheels: 48” deck, 23 x 9.50 x 12; 54”, 60", & 72” deck, 24x12 - 12
Frame: 2" Steel square tube and plate, all welded construction
Seat: Adjustable seat with armrests. 5" Adjustment
Fuel Tank: Two 6.5 gallon w/individual shutoff valves
Ground Speed: 0-10 + MPH forward. 0-4 MPH reverse
Instrumentation Hour meter, Tachometer, Maintenance-minder
Net Weight: 950 lbs w/48" deck, 980 lbs. w/54" deck, 1070 lbs. w/60" deck,
1330 lbs w/72” deck
