Two-Way Chute Control™ (optional)
This two-way control lever is meant to control the distance of
snow discharge from the chute. Tilt the lever forward or rearward
to adjust the distance snow will be thrown.
Chute Directional Control (optional)
The chute directional control can be turned clockwise or
counterclockwise to change the direction in which snow is
thrown.
CHUTE DIRECTIONAL CONTROL
DISCHARGE
LEFT
DISCHARGE
RIGHT
CHUTE TILT
DOWN
CHUTE TILT
UP
14 Section 4 — controlS and FeatureS

Cub Cadet 500 Series Specifications

General

Engine Type	4-Cycle OHV
Engine Displacement	208cc
Intake Height	21 inches
Auger Material	Steel
Auger Diameter	12 inches
Skid Shoes	Adjustable
Speeds	6 forward, 2 reverse
Chute Control	Crank
Starting System	Recoil
