Cub Cadet 528 SWE Illustrated Parts List

Ref.
Part Number Description
1. 731-2643 Clean-Out Tool
2. 712-04065 Flange Lock Nut
3. 756-0981B Flat Idler Pulley
4. 710-0347 Hex Bolt, 3/8-16 x 1.75
5. 790-00080A Auger Idler Bracket
6. 736-0174 Wave Washer
7. 738-0281 Shoulder Screw
8. 738-0143 Shoulder Screw
9. 790-00075 Bearing Housing
10. 726-04012 Push Nut
11. 712-04063 Flange Lock Nut, 5/16-18
12. 741-0309 Ball Bearing
13. 732-04460 Extension Spring
14. 710-04484 Hex Screw
15. 731-04705 Chute Adapter
16. 710-0703 Carriage Screw, 1/4-20 x 0.75
17. 731-2635 Clean-out Tool Mtg. Bracket
18. 684-04305 Housing Assembly, Auger, 22”
— 684-04259 Housing Assembly, Auger, 24”
— 684-04256 Housing Assembly, Auger, 26”
— 684-04257 Housing Assembly, Auger, 28”
— 684-04255 Housing Assembly, Auger, 30”
19. 712-04064 Flange Lock Nut, 1/4-20
20. 618-04190A Gearbox Assembly, Auger, 22”
— 618-04191A Gearbox Assembly, Auger, 24”
— 618-04192A Gearbox Assembly, Auger, 26”
— 618-04193A Gearbox Assembly, Auger, 28”
— 618-04194A Gearbox Assembly, Auger, 30”
21. 790-5580 Skid Shoe, Standard
— 790-00091 Skid Shoe, Deluxe
— 790-05984 Skid Shoe, Plastic
— 790-00141 Skid Shoe, Stainless
22. 710-0451 Carriage Bolt
23. 790-00117 Shave Plate, 22”
— 790-00120 Shave Plate, 24”
— 790-00121 Shave Plate, 26”
— 790-00118 Shave Plate, 28”
— 790-00119 Shave Plate, 30”
— 790-00148 Stainless Steel Shave Plate, 26”
— 790-00145 Stainless Steel, Shave Plate, 28
— 790-00146 Stainless Steel Shave Plate, 30”
Ref.
Part Number Description
24. 684-04057A Impeller Assembly
25. 717-04126 Worm Shaft
26. 721-0327 Oil Seal
27. 741-0662 Flange Bearing
28. 718-04071 Thrust Collar
29. 741-0663 Flange Bearing
30. 710-0642 TT Screw, 1/4-20 x 0.75
31. 790-00138A Bearing Housing
32. 721-0325 Plug
33. 736-3084 Flat Washer
34. 715-04021 Dowel Pin
35. 684-04108 Spiral Assembly- RH
36. 618-0123 Reducer Hsg.-RH (Incl Ref. 44-45)
37. 717-0528A Worm Gear, 20T
38. 725-0157 Cable Tie
39. 738-04124A Shear Pin
40. 714-0161 Hi-Pro Key
41. 736-0351 Flat Washer
42. 741-0661A Flange Bearing
43. 618-0418 Reducer Hsg.- LH
44. 711-04286 Axle, Auger, 22”
— 711-04285 Axle, Auger, 24”
— 711-04284 Axle, Auger, 26”
— 711-04283 Axle, Auger, 28”
— 711-04282 Axle, Auger, 30”
45. 684-04107 Spiral Assembly- LH
46. 714-04040 Bow Tie Cotter Pin
47. 731-04870 Spacer
48. 741-0493A Flange Bushing
49. 736-0188 Flat Washer
50. 741-0245 Hex Flange Bearing
51. 736-0242 Bell Washer
52. 629-0071 Extension Cord. 3-Prong
53. 746-04230 Auger Clutch Cable
54. 710-04525 Carriage Bolt, 5/16-18 x .750
55. 712-04103 Hex Nut, 5/16-18
56. 736-04216 Bell Washer, .340 x .872 x .060
57. 737-3000 Drive Lube Fitting
3
Auger & Auger Housing

Cub Cadet 528 SWE Specifications

General

Engine Type	4-cycle OHV
Engine Displacement	277cc
Clearing Width	28 inches
Intake Height	21 inches
Auger Diameter	12 inches
Speeds	6 forward / 2 reverse
Stages	Two-stage
Auger Material	Steel
Impeller Diameter	12 inches
Start Type	Recoil
Throw Distance	40 ft
Starter	Electric
Fuel Tank Capacity	5 qt
Skid Shoes	Adjustable
Warranty	3-year limited
Chute Rotation	200°
